Home > Product > Standalone DVR > Features

True Triplex Operation
The Specified performance of operation is independent with each other (true Triplex)

Mpeg4 Compression
Average 3~5Kbyte /frame (at CIF, 30fps)

Network
1 Ethernet port (Static IP/DHCP?DDNS supported)
Support network TX bandwidth Upper limit control / Adaptive Video Data Frame rate control under network condition

GUI
Full graphic GUI, Virtual keyboard supported

Recording
Modified Mpeg4 codec
Total Recording Capacity: 120fps max (NTSC), 100fps(PAL)
Video Resolution: 704 x 480/704x240/352x240 (each can be selected independent with other channels)

Archiving
AVI file format via CD-RW / USB port

Simple CMS (Multi site live monitoring)
Simultaneous each site DVR video can be monitored through network (Each Channel can be displayed simultaneously)
